Rakes & Tillers

Power Rakes

ModelRaking WidthLengthWeightMin. Hydraulic Flow
PR60 Power Rake
Raking Width
62 in. (1575 mm)
Length
59 in. (1499 mm)
Weight
938 lb. (425 kg)
Min. Hydraulic Flow
49 L/min. (13 gpm)
PR72B Power Rake
Raking Width
938 lb. (425 kg)
Length
64 in. (1625 mm)
Weight
925 lb. (419 kg)
Min. Hydraulic Flow
49 L/min. (13 gpm)
PR84B Power Rake
Raking Width
84 in. (2134 mm)
Length
64 in. (1625 mm)
Weight
1,050 lb. (476 kg)
Min. Hydraulic Flow
60 L/min. (16 gpm)
PR96B Power Rake
Raking Width
90 in. (2438 mm)
Length
76 in. (1930 mm)
Weight
1,320 lb. (598 kg)
Min. Hydraulic Flow
60 L/min. (16 gpm)

Root Rakes

ModelOverall WidthTime SpacingWeight
RR72 Root Rake
Overall Width
72 in. (1830 mm)
Time Spacing
9.5 in. (240 mm)
Weight
1,095 lb. (497 kg)
RR78 Root Rake
Overall Width
78 in. (1980 mm)
Time Spacing
10 in. (255 mm)
Weight
1,150 lb. (522 kg)
RR84 Root Rake
Overall Width
84 in. (2135 mm)
Time Spacing
8.5 in. (215 mm)
Weight
1,220 lb. (553 kg)

Rotary Tillers

ModelTilling WidthNumber of TinesOperating Weight
RT52 Tiller
Tilling Width
52 in. (1.3 m)
Number of Tines
24
Operating Weight
750 lb. (340 kg)
RT66 Tiller
Tilling Width
66 in. (1.7 m)
Number of Tines
32
Operating Weight
1,000 lb. (454 kg)
